COOL PRESS system is a copper press connection system designed for the air conditioning and refrigeration markets. It allows contractors to make secure leak-free connections in seconds. COOL PRESS utilizes a rubber stop ring, coated stainless steel grip ring and black HNBR sealing element to provide permanent leak-proof connections from 1/4" to 1 1/8".

COOL PRESS fittings are designed for the following applications.

· Refrigeration

· Air Conditioning

· Heat Pump(Refrigeration side)

· VRF and VRV

· Flame-free: Flame-free installation avoids the need for a fire permit and the risk of fire on site.

· No Nitrogen Purge: COOL PRESS is a mechanical joint, thus eliminating the need for nitrogen purge during the jointing process.

· Lower Installed Cost: A professional fitting which is quick and simple to install, saving time and money.

· Higher Productivity, Improved Flexibility: Work may be completed during working hours /public access, by a single employee.

· Site Access: Easy access to work sites, no gas bottles required.

· Quality Designed In: Reliable, repeatable, permanent, tamper-proof connections every time.

· 3-Point Press: Three press points, one each side of the bead, and one press com-pressing the O-ring. This provides a secure joint.

· High Quality O-ring: High quality HNBR O-ring forms a secure leak-free joint when pressed.

· Protected O-ring: Lead-in edge design aids tube insertion and helps protect the O-ring from damage or displacement.

· Electrical Continuity: Maintains ground continuity without the need for additional ground continuity straps.

· Field Proven: Press fit technology, field proven over two decades and millions of installed fittings worldwide.

· Compact Tooling: Light compact tooling provides easy access to tightly spaced tube runs.

· WARRANTY：15-year product warranty.

Continuous Operating Temperature

-40°F to 284°F/-40°C to 140°C



Maximum Rated Operating and Abnormal Pressure

700 psi / 48 bar / 4800 kPa



Burst Pressure

>3X Maximum operating and abnormal pressure

>2,100 psig />14400 kPa />144 bar



Vacuum Pressure Capability

200 Microns



Leak Tightness

Helium≤7.5 x 10 Pa.m /s at+20°C,10 bar



Size Availability (Inches)

1/4, 3/8,1/2, 5/8, 3/4, 7/8.1-1/8

Description

COOL PRESS system is a copper press connection system designed for the air conditioning and refrigeration markets. It allows contractors to make secure leak-free connections in seconds. COOL PRESS utilizes a rubber stop ring, coated stainless steel grip ring and black HNBR sealing element to provide permanent leak-proof connections from 1/4" to 1 1/8".

Applications

COOL PRESS fittings are designed for the following applications.

· Refrigeration

· Air Conditioning

· Heat Pump(Refrigeration side)

· VRF and VRV

Features and Benefits

· Flame-free: Flame-free installation avoids the need for a fire permit and the risk of fire on site.

· No Nitrogen Purge: COOL PRESS is a mechanical joint, thus eliminating the need for nitrogen purge during the jointing process.

· Lower Installed Cost: A professional fitting which is quick and simple to install, saving time and money.

· Higher Productivity, Improved Flexibility: Work may be completed during working hours /public access, by a single employee.

· Site Access: Easy access to work sites, no gas bottles required.

· Quality Designed In: Reliable, repeatable, permanent, tamper-proof connections every time.

· 3-Point Press: Three press points, one each side of the bead, and one press com-pressing the O-ring. This provides a secure joint.

· High Quality O-ring: High quality HNBR O-ring forms a secure leak-free joint when pressed.

· Protected O-ring: Lead-in edge design aids tube insertion and helps protect the O-ring from damage or displacement.

· Electrical Continuity: Maintains ground continuity without the need for additional ground continuity straps.

· Field Proven: Press fit technology, field proven over two decades and millions of installed fittings worldwide.

· Compact Tooling: Light compact tooling provides easy access to tightly spaced tube runs.

· WARRANTY：15-year product warranty.

Technical Data

Continuous Operating Temperature

-40°F to 284°F/-40°C to 140°C



Maximum Rated Operating and Abnormal Pressure

700 psi / 48 bar / 4800 kPa



Burst Pressure

>3X Maximum operating and abnormal pressure

>2,100 psig />14400 kPa />144 bar



Vacuum Pressure Capability

200 Microns



Leak Tightness

Helium≤7.5 x 10 Pa.m /s at+20°C,10 bar



Size Availability (Inches)

1/4, 3/8,1/2, 5/8, 3/4, 7/8.1-1/8
